Output
- Output power capacity: 4.2 KWatts / 6.0 kVA
- Max Configurable Power (Watts) : 4.2 KWatts / 6.0 kVA
- Nominal Output Voltage: 230V
- Output Voltage Note : Configurable for 220 : 230 or 240 nominal output voltage
- Output Voltage Distortion : Less than 3%
- Output Frequency (sync to mains) : 50/60 Hz +/- 3 Hz user adjustable +/- 0.1
- Other Output Voltages : 220, 240
- Load Crest Factor : 3 : 1
- Topology : Double Conversion Online
- Waveform type : Sine wave
- Output Connections :
(4) IEC Jumpers (Battery Backup)
(2) IEC 320 C19 (Battery Backup)
(8) IEC 320 C13 (Battery Backup)
- Bypass : Internal Bypass (Automatic and Manual)
Input
- Nominal Input Voltage : 230V
- Input frequency : 50/60 Hz +/- 5 Hz (auto sensing)
- Input Connections : Hard Wire 3-wire
- Input voltage range for main operations : 160 - 280V
- Input voltage adjustable range for mains operation : 100 - 280V
- Other Input Voltages : 220, 240
Batteries & Runtime
- Battery type : Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
- Included Battery Modules : 2
- Typical recharge time : 2.5hour(s)
- Extendable Run Time : 1
- Battery Volt-Amp-Hour Capacity : 1056
- Extended Run Options : APC-Smart-UPS-RT-6000VA-230V
- Runtime : View Runtime Graph, View Runtime Chart
- Efficiency : View Efficiency Graph
Communications & Management
- Interface Port(s) : DB-9 RS-232 , RJ-45 10/100 Base-T , Smart-Slot
- Pre-Installed SmartSlot™ Cards : AP9631
Physical
- Maximum Height : 432mm , 43.2cm
- Maximum Width : 130mm , 13.0cm
- Maximum Depth : 660mm , 66.0cm
- Rack Height : 3U
- Net Weight : 54.43kg
- Shipping weight : 63.64kg
- Shipping Height : 347mm , 34.7cm
- Shipping Width : 603mm , 60.3cm
- Shipping Depth : 980mm , 98.0cm
- Color: Black
- Master Carton Units : 1.0
- Units per Pallet : 6.0
Environmental
- Operating Environment : 0 - 40 °C
- Operating Relative Humidity : 0 - 95% non-condensing %
- Operating Elevation : 0-3000meters
- Storage Temperature: -15 - 45 °C
- Storage Relative Humidity : 0 - 95% non-condensing %
- Storage Elevation : 0-15000meters
- Audible noise at 1 meter from surface of unit : 55.0dBA
- Online thermal dissipation : 1221.0BTU/hr
- Protection Class : IP 20
Conformance
- Approvals: C-tick, CE, CSA, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 60950, EN 61000-3-2, GOST, UL Listed, VDE
- Standard warranty: 2 years repair or replace, optional on-site warranties available, optional extended warranties available
Sustainable Offer Status
